Operated by key outside and thumb turn inside. Door Prep: 2-1/8 in or 1-1/2 in crossbore; 1 in edge bore; 1 x 2-1/4 in latch face. Door Thickness: 1-3/8 in to 1-3/4 in standard. 1-7/8 in to 2-1/4 in optional. Cylinder: 5-pin SmartKey cylinder. Faceplate: 1 x 2-1/4 in. Strike: 1-1/4 x 3-5/8 in. Bolt: 1 in throw, stainless steel. Handing: Reversible for right or left hand doors. ANSI/BHMA: Grade 2. ADA: Interior turn piece meets 4.13.9 ADA requirements. Deadbolts with SmartKey in (denoted SMT) feature allow, in 3 steps, locks to be re-keyed to a spare set of keys. When the spare keys are done being used, the lock can be re-keyed back to the original set of keys; can continually be re-keyed.
Products specifications
|
Cylinder Type
|
5-Pin |
|
Dimensions
|
2-1/2 in Dia x 15/16 in L |
|
Faceplate Size
|
1 x 2-1/4 in |
|
Finish
|
Polished Brass |
|
Key Type
|
Alike |
|
Keyway Type
|
K3 |
|
Material
|
Stainless Steel |
|
Number of Cylinders
|
1 |
|
Strike Size
|
1-1/4 x 3-5/8 in |
|
Strike Type
|
Round Corner |
|
Suitable for
|
1-3/8 to 1-3/4 in Thick Doors |
|
Throw Length
|
1 in |
|
Manufacturer
|
KWIKSET |
